Thông số

24V DC ±10% input
• Battery
• Power Supply: full-wave rectified with smoothed current and < 10% Ripple
• Power ON delay < 1s
• 4A locking current
• Input signal level for activation
• 0V (3V or less) for NPN
• 24V (18V or greater) for PNP
• Output (Error and Motor Pulse) signals
• Open collector 24V, 25mA or less
• NPN
• PNP (selectable for Error only)
• Brake model only
• 0.2s delay between stop signal and mechanical brake reaction
• 0.2A brake current @24V (< 0.1s)
• Brake coil is active (disengaging brake) while the motor is running
